Big Ton Spring Supports

A big ton spring is a multi-spring coil device that lends itself to supporting very high loads and providing a great amount of stability. They are used in applications where the combination of heavy loads and thermal expansion are required.

Types & Sizes

Fig 500-Big Ton Spring Support
Big Ton supports are designed primarily for the petrochemical industry where two important characteristics in spring supports are necessary:

  1. Stability: Big Ton spring supports are extremely stable. Base supports springs of this design are frequently used under horizontal pressure vessel saddle supports in combination with slide plates or roller supports. Our Big Ton design lends itself ideally to this support situation. Type F design is sufficient where there is a minimal amount of lateral movement, but where the combination of heavy loads and thermal expansion are required, Big Ton industrial springs should be your choice.
  2. Heavy Loads: Big Ton multi-spring design lends itself to supporting very high loads. The load values can be modified to accommodate the client’s needs. Loads up to 200,000 lb. can be handled with no problems. The designs which appear in the load table are “off-the-shelf” designs and can be shipped with good delivery dates. Designs above those shown in the load table will be furnished upon request.

Technical Information

Installation & Maintenance

Request A Quote



Ammonia Plant
Chemical Plant
Clean Fuels
Commercial

Electric Plant
Energy Facility
Ethylene Plant
LLDPE Chemical Plant

LNG Plant
MTBE Plant
Natural Gas Combined Cycle Facility
Natural Gas Processing & Separation

Oil Refinery
Oil Sand Mine
Paper Manufacturer
See All

See More Images

An alternative to a U-Type or F-Type variable spring depends upon the load AND the application, but a big ton ...Continue Reading

To adjust a big ton spring, you would rotate the nuts that are located on top of the plate pressing ...Continue Reading

No, you cannot encapsulate a Big Ton; it must have space to accommodate the movement. A Big Ton with a ...Continue Reading

Big Ton’s springs run parallel to one another.


More FAQs…

GENERAL DIMENSIONS & SPECIFICATIONS

Download PDF

Fig 500-Big Ton Spring Support

Fig. 500-Big Ton Spring Support
ORDERING: Specify figure number, spring rate, description, design load and travel.
NOTES:
1. Paint shims red, Item 10 remove in field.
2. Field to remove lifting eye-bolts Item 21.
3. Shipping Wt. = (lb.)
SPECIFICATIONS:
1. Design Load = (lb.)
2. Deflection: Up & Down = (in.)
3. Spring Rate = (lb./in.)
4. Shipping Wt. = (lb.)

Material Items
ITEM NO.QTY.DESCRIPTION
11TOP LOAD FLANGE
21BOTTOM FLANGE
32SIDE PLATE
42SLIDE PLATE TOP BAR
52SLIDE PLATE BTM. BAR
61SPRING BTM. SUPPORT PLATE
73STUD PRESSURE PLATE
86PRESSURE PLATE GUIDE BARS
93SPRING PRESSURE PLATE
104SHIM PLATES
116LOAD STUDS
126LOAD STUD NUTS
136LOAD STUD WASHERS
1412COVER PLATE BOLTS
154LIFTING NUTS
168LIMIT STOP STUDS
178LIMIT STOP WASHERS
188LIMIT STOP NUTS
192COVER PLATES
202COVER PLATE GASKET
214LIFTING EYE BOLTS
221NAME PLATE
234SIDE PLATE VERTICAL BARS
249OUTER SPRING
25-INNER SPRING (AS REQ’D)

<!–

ITEM NO. QTY. DESCRIPTION
1 1 TOP LOAD FLANGE
2 1 BOTTOM FLANGE
3 2 SIDE PLATE
4 2 SIDE PLATE TOP BAR
5 2 SIDE PLATE BTM. BAR
6 1 SPRING BTM. SUPPORT PLATE
7 3 STUD PRESSURE PLATE
8 6 PRESSURE PLATE GUIDE BARS
9 3 SPRING PRESSURE PLATE
10 4 SHIM PLATES
11 6 LOAD STUDS
12 6 LOAD STUD NUTS
13 6 LOAD STUD WASHERS
14 12 COVER PLATE BOLTS
15 4 LIFTING NUTS
16 8 LIMIT STOP STUDS
17 8 LIMIT STOP WASHERS
18 8 LIMIT STOP NUTS
19 2 COVER PLATES
20 2 COVER PLATE GASKET
21 4 LIFTING EYE BOLTS
22 1 NAME PLATE
23 4 SIDE PLATE VERTICAL BARS
24 9 OUTER SPRING
25 INNER SPRING (AS REQ’D)

–>
45,000 Lb. Load Boiler Spring Assemblies For A Power Plant

45,000 Lb. Load Boiler Spring Assemblies For A Power Plant
